unit
|
item
|
specification
|
description
|
note
|
|
Extruding
(outer
layer-original material)
|
Screw
diameter
|
φ50mm
|
Mixing
model
|
|
|
Screw
L/D
|
25 : 1
|
|
|
|
Material
of screw and barrel
|
|
38CrMoALA
|
|
|
Plasticizing
capacity
|
45KG/Hr
|
HDPE
|
|
|
Extruding
method
|
Motor,
gear box, strap driving
|
Invertor
motor, hardness tooth surface gear box
|
|
|
Driving
power
|
11KW
|
|
|
|
Screw
revolution
|
10—100V/min
|
|
|
|
Heating
zones
|
3
|
Temperature
medule from Mitsubishi
|
|
|
Heating
power
|
3φ2.6KW
|
|
|
|
Blowers
|
3
|
Power
120W
|
|
|
Cooling
|
Yes
|
Cooling
water for feeding zone and gear box
|
|
|
Extruding
(inner
layer-recycled material)
|
Screw
diameter
|
φ80mm
|
Mixing
model
|
|
|
Screw
L/D
|
25?1
|
|
|
|
Material
of screw and barrel
|
|
38CrMoALA
|
|
|
Plasticizing
capacity
|
110 KG/Hr
|
HDPE
|
|
|
Extruding
method
|
Motor,
gear box, strap driving
|
Invertor
motor, hardness tooth surface gear box
|
|
|
Driving
power
|
22KW
|
|
|
|
Screw
revolution
|
10—90V/min
|
|
|
|
Heating
zones
|
3
|
Temperature
medule from Mitsubishi
|
|
|
Heating
power
|
3φ5.4KW
|
|
|
|
Blowers
|
3
|
Power
120W
|
|
|
Cooling
|
Yes
|
Cooling
water for feeding zone and gear box
|
|
|
Extruding
(layer
for view stripe
|
Screw
diameter
|
φ30mm
|
Mixing
model
|
|
|
Screw
L/D
|
22?1
|
|
|
|
Material
of screw and barrel
|
|
38CrMoALA
|
|
|
Plasticizing
capacity
|
16 KG/Hr
|
HDPE
|
|
|
Extruding
method
|
Motor,
reducer and drive basement
|
Cycloid
needle wheel reducer, drive basement and transducer
|
|
|
Driving
power
|
3KW
|
|
|
|
Screw
revolution
|
10—85V/min
|
|
|
|
Heating
zones
|
2
|
Temperature
medule from Mitsubishi
|
|
|
Heating
power
|
2φ1.2KW
|
|
|
|
Blowers
|
2
|
Power
120W
|
|
|
Cooling
|
Yes
|
Cooling
water for feeding zone and gear box
|
|
|
Clamping
unit (double)
|
Structure
|
|
Large
arm and joint operation type, with large and average clamping force
|
Patent
|
|
Idle cycle time
|
800×2 pc/h
|
|
|
|
Platen
dimension
|
530×510mm
|
W * H
|
|
|
Platen
distance
|
240~620mm
|
|
|
|
Clamping
force
|
110KN
|
|
|
|
Mold
thickness scope
|
240~360 mm
|
|
|
|
Mold moving stroke
|
Induce switch + moving
|
Discriminate end of mold moving up,
low-speed of mold moving up, end of mold moving down and low-speed of mold
moving down
|
|
|
Clamping stroke
|
Stroke switch + moving
|
Discriminate end of mold opening,
end of mold closing and low-speed of mold closing
|
|
|
Triple
head with double layer, with view stripe
|
Center
distance
|
|
160mm
|
|
|
Structure
|
Continuous
|
Central
feeding
|
|
|
Material
|
|
38CrMoALA
inner mirror
|
|
|
Die
mouth
|
Φ25~Φ145 mm
|
|
|
|
Heating
method
|
|
Stainless
steel band
|
|
|
Heating
zones
|
9
|
|
|
|
Diehead
blowing
|
Yes
|
|
|
|
Parison
thickness controlling
|
Available
|
MOOG
30-point
|
Selectable
|
|
Parison
adjustment method
|
Outer
mandral
|
|
|
|
Adjustment
|
±2mm
|
|
|
|
Up
blowing unit
|
|
|
Use
up blowing, could equip signal head, signal blowing, double head, double
blowing, three head, three blowing
|
|
|
Controlling
system
|
Temperature
|
Module
|
Mitsubishi
|
|
|
Programmer
|
Taiwan
|
Adopt PLC module with alarm and P?L?D
control
|
|
|
Overload
protection
|
|
Set electricity
oxygen protection according to the product specification, preventing damage
when electric power overload
|
|
|
Programmer
|
Mitsubishi PLC
|
The
movement programmer
composed in general language, and movement control may be revised according
to the users’ special demand
|
|
|
Control interface
|
Human interface screen
|
HITECH human interface screen with several color Made in Taiwan
|
|
|
Time
|
Touch screen
|
Set pressure and timing on the screen to
manage and control the movement
|
|
|
Hydraulic
|
Oil
motor power
|
11KW
|
|
|
|
Brand
|
Double foil pump
|
Taiwan
HYTEK
|
|
|
Controlling
|
Proportional
|
|
|
|
Max.
working pressure
|
140 kg/cm2
|
|
|
|
Pneumatics
|
Direction
|
|
AIRTEC
from Taiwan
|
|
|
Pressure
controlling
|
|
Separate
two adjusters for high and low pressure
|
|
Max.
pressure
|
8kg/cm, 1.0m3/min
|
All air pipes are connected by PU pipe
|
|
Other
information
|
Lubricative method
|
|
Manual lubricate oil pump
|
|
|
Cooling of oil
|
|
Recycle oil is cooled by oil cooled heat
exchanger
|
|
|
Mold
cooling
|
|
Separated
cooling water resource, use 2-in 2-out fix (single side)
|
|
|
Gear box,
hopper basement, die head cooling
|
|
Use
separated cooling water circuit, insure cooling effect
|
|
|
Overall
dimension
|
L
* W * H
|
4100*2900*3100 mm
|
|
|
Weight
|
10.8T
|
|
|
